304 316L Stainless Steel Pipe Temperature Sensor Custom Non Standard Shape

Name: 304 316L Stainless Steel Pipe Temperature Sensor Custom Non Standard Shape
Brand: yue lin sen
Price: 0.5 USD

Buy cheap 304 316L Stainless Steel Pipe Temperature Sensor Custom Non Standard Shape product

Brand Name : yue lin sen

Model Number : Y56

Certification : ISO9001 ISO13485

Place of Origin : Dongguan, Guangdong

MOQ : 100 pcs

Price : 0.5-20

Payment Terms : T/T

Supply Ability : 500000pcs5

Delivery Time : 5-8 work days

Packaging Details : vacuum packaging; cardboard box

Outer Diameter : Customizable

Length : Customizable

Shape : Round

Wall Thickness : Customizable

Flexibility : Low

Material : Stainless Steel

Application : Medical, Industrial, Laboratory

Size : Customizable

Inner Diameter : Customizable

Surface Finish : Polished

Corrosion Resistance : High

Durability : High

Temperature Resistance : High

Contact Now

304 316L Stainless Steel Pipe Sensor Temperature Sensor Custom Non-Standard Shape

304 316L Stainless Steel Pipe Temperature Sensor Custom Non Standard Shape Product Description

This product is a high-performance Temperature Sensor engineered from premium 304 or 316L Stainless Steel pipe or housing. It is specifically designed for applications demanding exceptional corrosion resistance, durability, and reliability in harsh environments. The key differentiator is its capability for custom non-standard shapes, allowing for perfect integration into complex or space-constrained systems where off-the-shelf sensors are not suitable.

Product Attribute	Description
Core Product	Temperature Sensor (e.g., RTD, Thermocouple, Thermistor)
Primary Material	304 or 316L Stainless Steel Pipe / Sheath
Key Feature	Fully Customizable Non-Standard Shapes & Dimensions
Target Applications	Chemical Processing, Pharmaceutical, Food & Beverage, Semiconductor, HVAC, Power Generation, Marine, and Specialized OEM Machinery.
General Benefits	Excellent corrosion resistance, high-temperature tolerance, robust mechanical strength, and long-term stability.

Product Technical Parameters

The following parameters are typical and can be adjusted based on the specific custom requirements.

Parameter Category	Specification	Notes
Sensor Material Options	304 Stainless Steel: Good general corrosion resistance. 316L Stainless Steel: Superior corrosion resistance, especially against chlorides and acids.	Material selection depends on the application media.
Sheath/Pipe Diameter	Customizable (e.g., from 3mm to 25mm or larger)	Diameter is tailored to fit the installation space and thermal response needs.
Sheath/Pipe Length	Fully Customizable	Designed to meet the exact immersion length requirement.
Bending & Shape	Custom bends, coils, flanges, threads, or complex geometries.	CAD drawings can be used to define precise shapes for direct fit.
Temperature Range	Standard Range: -50°C to +500°C (-58°F to +932°F) Extended Range: Depending on sensor type and fill material, can be higher.	The actual range depends on the internal sensing element and assembly.
Pressure Rating	Varies with sheath diameter, wall thickness, and material.	Designed to withstand the system's operating pressure.
Electrical Connection	Customizable (e.g., Terminal Head, Connector, Cable Exit, Flying Leads).	Chosen for environmental protection (IP rating) and ease of installation.
Accuracy / Class	Depends on the sensing element (e.g., RTD Class A, B; Thermocouple Standard or Special Limits).	Specified according to application precision requirements.

Product Customization Advantages

The ability to create a non-standard shape provides significant benefits over using a standard, straight sensor.

Advantage	Description
Perfect System Integration	The sensor can be designed to fit precisely into complex assemblies, avoiding interference with other components and eliminating the need for awkward adaptations.
Optimized Performance	Custom shapes ensure the sensing tip is positioned in the exact optimal location for accurate temperature measurement of the media (liquid, gas, or surface).
Space Efficiency	Ideal for compact equipment where a standard sensor would not fit. Bends and coils can be designed to maximize surface contact or length within a confined space.
Enhanced Durability	A custom-shaped sensor can be designed to minimize stress points and vibrations, leading to improved mechanical longevity and reliability.
Simplified Installation	Pre-formed shapes with specific mounting features (like flanges or brackets) can drastically reduce installation time and complexity, lowering overall costs.
Material Flexibility	The choice between 304 and 316L stainless steel allows for cost-effective solutions or maximum corrosion resistance, tailored to the specific environmental conditions.
Solution for Unique Problems	Provides an engineered solution for applications where no standard sensor exists, enabling innovation and functionality in specialized machinery and processes.
